The G-400 EYE NUT provides an eye connection on a compatible threaded stud or bolt. Match the thread and eye dimensions to the installation and the specified loading arrangement.
The G-400 EYE NUT provides an eye connection on a compatible threaded stud or bolt. Match the thread and eye dimensions to the installation and the specified loading arrangement.
![]()
| Size | Std.Tap | WLL | Dimensions(in) | Weight | |||||||||
| ("S") | size | (lbs) | A | C | D | E | F | J | K | N | T | W | 100pcs |
| (in) | (lbs) | ||||||||||||
| 0.25 | 1/4 | 520.00 | 1.25 | 0.75 | 1.00 | 0.75 | 0.50 | 0.69 | 0.63 | 0.38 | 1.72 | 0.31 | 0.09 |
| 0.31 | 3/8 | 1250.00 | 1.62 | 1.00 | 1.20 | 0.83 | 0.56 | 0.81 | 0.89 | 0.50 | 2.09 | 0.41 | 0.17 |
| 0.38 | 1/2 | 2250.00 | 2.00 | 1.25 | 1.44 | 1.08 | 0.81 | 1.00 | 1.09 | 0.62 | 2.55 | 0.50 | 0.28 |
| 0.50 | 5/8 | 3600.00 | 2.50 | 1.50 | 1.92 | 1.35 | 1.00 | 1.31 | 1.31 | 0.69 | 3.25 | 0.69 | 0.60 |
| 0.63 | 3/4 | 5200.00 | 3.00 | 1.75 | 2.38 | 1.59 | 1.12 | 1.50 | 1.57 | 0.88 | 3.89 | 0.84 | 1.00 |
| 0.75 | 7/8 | 7200.00 | 3.50 | 2.00 | 2.63 | 1.96 | 1.38 | 1.88 | 1.77 | 0.94 | 4.32 | 1.00 | 1.65 |
| 0.88 | 1 | 10000.00 | 4.00 | 2.25 | 3.06 | 2.21 | 1.56 | 2.13 | 2.02 | 1.07 | 5.01 | 1.19 | 2.69 |
| 1.00 | 1 1/4 | 15500.00 | 4.50 | 2.50 | 3.50 | 2.46 | 1.88 | 2.38 | 2.27 | 1.25 | 5.78 | 1.38 | 4.38 |
| 1.13 | 1 3/8 | 18580.00 | 5.00 | 2.75 | 4.00 | 2.69 | 2.00 | 2.56 | 2.53 | 1.38 | 6.51 | 1.50 | 5.00 |
| 1.25 | 1 1/2 | 22500.00 | 5.62 | 3.12 | 4.31 | 3.09 | 2.25 | 3.00 | 2.82 | 1.50 | 7.06 | 1.66 | 6.78 |
| 1.50 | 2 | 40000.00 | 7.12 | 4.10 | 6.20 | 4.09 | 3.13 | 3.75 | 3.68 | 2.06 | 9.91 | 1.94 | 14.60 |
Threaded attachment points selected to the model rating.
To request G-400 EYE NUT, please specify thread diameter and pitch, eye dimensions, material and required rated load. Include the quantity, delivery destination and any packaging or documentation requirements so our team can confirm the available configuration.
Throughout more than 23 years, has built an enviable reputation as a leading supplier of rigging hardware products, chains and steel wire rope accessories.
Really happy with these G‑400 eye nuts. Solid build, holds up well under working load. Easy to install for machinery lifting and anchoring. Exactly what our project needed.
