| Size | Std.Tap | WLL | Dimensions(in) | Weight | |||||||||
| ("S") | size | (lbs) | A | C | D | E | F | J | K | N | T | W | 100pcs |
| (in) | (lbs) | ||||||||||||
| 0.25 | 1/4 | 520.00 | 1.25 | 0.75 | 1.00 | 0.75 | 0.50 | 0.69 | 0.63 | 0.38 | 1.72 | 0.31 | 0.09 |
| 0.31 | 3/8 | 1250.00 | 1.62 | 1.00 | 1.20 | 0.83 | 0.56 | 0.81 | 0.89 | 0.50 | 2.09 | 0.41 | 0.17 |
| 0.38 | 1/2 | 2250.00 | 2.00 | 1.25 | 1.44 | 1.08 | 0.81 | 1.00 | 1.09 | 0.62 | 2.55 | 0.50 | 0.28 |
| 0.50 | 5/8 | 3600.00 | 2.50 | 1.50 | 1.92 | 1.35 | 1.00 | 1.31 | 1.31 | 0.69 | 3.25 | 0.69 | 0.60 |
| 0.63 | 3/4 | 5200.00 | 3.00 | 1.75 | 2.38 | 1.59 | 1.12 | 1.50 | 1.57 | 0.88 | 3.89 | 0.84 | 1.00 |
| 0.75 | 7/8 | 7200.00 | 3.50 | 2.00 | 2.63 | 1.96 | 1.38 | 1.88 | 1.77 | 0.94 | 4.32 | 1.00 | 1.65 |
| 0.88 | 1 | 10000.00 | 4.00 | 2.25 | 3.06 | 2.21 | 1.56 | 2.13 | 2.02 | 1.07 | 5.01 | 1.19 | 2.69 |
| 1.00 | 1 1/4 | 15500.00 | 4.50 | 2.50 | 3.50 | 2.46 | 1.88 | 2.38 | 2.27 | 1.25 | 5.78 | 1.38 | 4.38 |
| 1.13 | 1 3/8 | 18580.00 | 5.00 | 2.75 | 4.00 | 2.69 | 2.00 | 2.56 | 2.53 | 1.38 | 6.51 | 1.50 | 5.00 |
| 1.25 | 1 1/2 | 22500.00 | 5.62 | 3.12 | 4.31 | 3.09 | 2.25 | 3.00 | 2.82 | 1.50 | 7.06 | 1.66 | 6.78 |
| 1.50 | 2 | 40000.00 | 7.12 | 4.10 | 6.20 | 4.09 | 3.13 | 3.75 | 3.68 | 2.06 | 9.91 | 1.94 | 14.60 |
Throughout more than 23 years, has built an enviable reputation as a leading supplier of rigging hardware products, chains and steel wire rope accessories.
Our Japanese‑style extended long shank eye bolts strictly comply with JIS standard, made of high‑strength carbon steel, hot‑dip galvanized for rust & corrosion resistance. Extended long shank design meets special installation needs for construction, lifting, marine and heavy‑industry rigging scenarios. Available in full sizes, support OEM customization, factory direct supply with stable quality & fast delivery.
This heavy-duty winch shackle with integrated pulley roller sheave is designed for 4x4 off-road recovery, winching, and towing operations. Made of drop-forged carbon steel with heat treatment, it offers exceptional strength with a 4.75-ton working load limit and 6:1 safety factor. The shackle body is coated in bright orange for high visibility and corrosion resistance, while the smooth black pulley reduces rope wear during winching. The bolt-type design with safety cotter pin ensures secure and reliable connection, making it ideal for off-road vehicles, trucks, Jeeps, and heavy-duty recovery scenarios.
IS B1169 lifting eye nut is manufactured in accordance with Japanese industrial standards. Adopts drop-forged process with high strength and excellent load-bearing capacity. Available in carbon steel and stainless steel SUS304/SUS316. Multiple surface treatments such as zinc plating and hot-dip galvanized for anti-rust and corrosion resistance. Clear load marking, safe and reliable. Widely used for machinery, molds, containers and industrial hoisting rigging.
Factory direct G291 eye bolt, strictly produced per US standard. Drop-forged, integral heat treatment for maximum durability and wear resistance. Hot-dip galvanized after threading, supplied with matching hex nuts. Complete specifications, OEM/ODM supported. Professional heavy duty lifting rigging fitting for global industrial customers.
G279 forged eye nut is American standard lifting hardware, made of high strength carbon steel by drop forging process. Featured with strong load capacity, high toughness and stable structure. Hot dip galvanized or zinc plated surface provides excellent rust and corrosion resistance. Compliant with industrial rigging standards, widely used for machinery lifting, equipment anchoring, construction and marine hoisting. Durable and safe for heavy duty working conditions.
DIN 580 stainless steel eye bolt is made of high-quality stainless steel, produced strictly in accordance with DIN 580 standard. It features high tensile strength, precise thread size, smooth surface and excellent load-bearing performance. With outstanding rust and corrosion resistance, it is suitable for marine environment, mechanical lifting, rigging connection, equipment fastening and outdoor engineering applications. Complete standard sizes are available, OEM and customized service are supported.
DIN 582 stainless steel eye nut is strictly manufactured according to DIN 582 standard. Made of premium stainless steel, it features high tensile strength, precise thread and smooth round eye design. Excellent rust and corrosion resistance ensures reliable performance in marine, outdoor and humid environments. Widely used for lifting connection, rigging assembly, equipment fastening and industrial suspension applications. Complete standard sizes are available, OEM and customized service are supported.
