| WEIGHT EACH （KG） | DIMENSIONS（MM） | TOLERANCE +/- | |||||||||
| A | B | C | D | E | F | H | L | N | G | A | |
| 0.03 | 9.65 | 6.35 | 22.40 | 4.85 | 15.20 | 14.20 | 37.30 | 24.90 | 4.85 | 1.50 | 1.50 |
| 0.05 | 11.90 | 7.85 | 28.70 | 6.35 | 19.80 | 15.50 | 46.70 | 32.50 | 6.35 | 1.50 | 1.50 |
| 0.10 | 13.50 | 9.65 | 31.00 | 7.85 | 21.30 | 19.10 | 53.00 | 37.30 | 7.85 | 3.30 | 1.50 |
| 0.15 | 16.80 | 11.20 | 36.60 | 9.65 | 26.20 | 23.10 | 63.00 | 45.20 | 9.65 | 3.30 | 1.50 |
| 0.22 | 19.10 | 12.70 | 42.90 | 11.20 | 29.50 | 26.90 | 74.00 | 51.50 | 11.20 | 3.30 | 1.50 |
| 0.36 | 20.60 | 16.00 | 47.80 | 12.70 | 33.30 | 30.20 | 83.50 | 58.50 | 12.70 | 3.30 | 1.50 |
| 0.76 | 26.90 | 19.10 | 60.50 | 16.00 | 42.90 | 38.10 | 106.00 | 74.50 | 17.50 | 6.35 | 1.50 |
| 1.23 | 31.80 | 22.40 | 71.50 | 19.10 | 51.00 | 46.00 | 126.00 | 89.00 | 20.60 | 6.35 | 1.50 |
| 1.79 | 36.60 | 25.40 | 84.00 | 22.40 | 58.00 | 53.00 | 148.00 | 102.00 | 24.60 | 6.35 | 1.50 |
| 2.57 | 42.90 | 28.70 | 95.50 | 25.40 | 68.50 | 60.50 | 167.00 | 119.00 | 26.90 | 6.35 | 1.50 |
| 3.75 | 46.00 | 31.80 | 108.00 | 28.70 | 74.00 | 68.50 | 190.00 | 131.00 | 31.80 | 6.35 | 3.30 |
| 5.31 | 51.50 | 35.10 | 119.00 | 31.80 | 82.50 | 76.00 | 210.00 | 146.00 | 35.10 | 6.35 | 3.30 |
| 7.18 | 57.00 | 38.10 | 133.00 | 35.10 | 92.00 | 84.00 | 233.00 | 162.00 | 38.10 | 6.35 | 3.30 |
| 9.43 | 60.50 | 41.40 | 146.00 | 38.10 | 98.50 | 92.00 | 254.00 | 175.00 | 41.10 | 6.35 | 3.30 |
| 15.40 | 73.00 | 51.00 | 178.00 | 44.50 | 127.00 | 106.00 | 313.00 | 225.00 | 57.00 | 6.35 | 3.30 |
| 23.70 | 82.50 | 57.00 | 197.00 | 51.00 | 146.00 | 122.00 | 348.00 | 253.00 | 61.00 | 6.35 | 6.35 |
| 44.6 | 105.00 | 70.00 | 267.00 | 66.50 | 184.00 | 145.00 | 453.00 | 327.00 | 79.50 | 6.35 | 6.35 |
| 70 | 127.00 | 82.50 | 330.00 | 76.00 | 200.00 | 165.00 | 546.00 | 365.00 | 92.00 | 6.35 | 6.35 |
| 120 | 133.00 | 95.50 | 372.00 | 92.00 | 229.00 | 203.00 | 626.00 | 419.00 | 105.00 | 6.35 | 6.35 |
| 153 | 140.00 | 108.00 | 368.00 | 104.00 | 254.00 | 229.00 | 653.00 | 468.00 | 116.00 | 6.35 | 6.35 |
Throughout more than 23 years, has built an enviable reputation as a leading supplier of rigging hardware products, chains and steel wire rope accessories.
High quality DIN 82101 D-type shackle, drop forged carbon steel material, heat treated for high tensile strength. Available in hot dip galvanized and plain finish, good anti-rust performance. Standard European type Dee shackle with stable working load limit, safe 6:1 safety factor. Widely used for lifting, rigging, towing, marine, construction and cargo binding. Strict quality inspection, durable and reliable for heavy duty industrial use.
Premium S209/G209 screw pin anchor shackle made by integrated drop forging and heat treatment, high tensile and fatigue-resistant structure without casting defects. Dimension fully consistent with international US G209 specification, interchangeable with mainstream branded shackles. Strict impact and breaking load inspection, suitable for fishing trawler, vessel anchor connection, heavy engineering lifting and mining rigging. We provide official load test certificates and flexible MOQ for worldwide distributors.
