| Size (mm) | Dimensions(mm) | Weight | |||||
| 100pcs | |||||||
| Rope Dia. | A | B | C | D | E | F | (kg) |
| 8 | 9 | 15 | 40 | 66 | 14 | - | 18 |
| 10 | 11 | 17.5 | 50 | 82 | 18 | - | 32 |
| 12 | 13 | 20 | 60 | 98 | 21 | - | 52 |
| 14 | 16 | 23.5 | 70 | 114 | 25 | - | 80 |
| 16 | 18 | 26 | 80 | 130 | 28 | 16 | 90 |
| 18 | 20 | 28.5 | 90 | 145 | 31 | 18 | 121 |
| 20 | 22 | 31 | 100 | 161 | 35 | 20 | 161 |
| 22 | 24 | 33.5 | 110 | 177 | 38 | 22 | 211 |
| 24 | 26 | 36 | 120 | 193 | 41 | 24 | 271 |
| 26 | 29 | 39.5 | 130 | 209 | 44 | 26 | 355 |
| 28 | 31 | 42 | 140 | 224 | 47 | 28 | 420 |
| 32 | 35 | 47 | 160 | 256 | 53 | 32 | 630 |
| 36 | 40 | 53 | 180 | 288 | 59 | 36 | 884 |
| 40 | 44 | 58 | 200 | 320 | 65 | 40 | 1100 |
| 44 | 48 | 63 | 220 | 352 | 70 | 44 | 1500 |
| 48 | 53 | 69 | 240 | 384 | 76 | 48 | 2000 |
| 52 | 57 | 74 | 260 | 416 | 81 | 52 | 2500 |
| 56 | 62 | 80 | 280 | 448 | 86 | 56 | 3200 |
| 64 | 70 | 90 | 320 | 512 | 95 | 64 | 4600 |
| 72 | 79 | 101 | 360 | 576 | 104 | 72 | 6600 |
| 80 | 88 | 112 | 400 | 640 | 112 | 80 | 9000 |
DIN3091 heavy duty wire rope thimble is placed inside wire rope eye splice to protect the rope eye from crushing, bending and abrasion, maintain the shape of rope loop, improve sling breaking strength and extend rope service life, widely used for wire rope slings, lifting rigging, marine mooring, port handling, tower crane, steel structure hoisting, power installation, mining and heavy equipment lashing.
