The DIN 1480 Stub End Turnbuckle adjusts the tension and effective length of a compatible wire or tie assembly. Compare the body length, thread and end configuration in the drawing.
The DIN 1480 Stub End Turnbuckle adjusts the tension and effective length of a compatible wire or tie assembly. Compare the body length, thread and end configuration in the drawing.
![]()
| Size(a) | Dimensions(mm) | Weight | |||||
| (mm) | b | c | d | e | f | g | (kg) |
| 6 | 240 | 326 | 110 | 86 | 120 | 65 | 0.093 |
| 8 | 240 | 320 | 110 | 80 | 120 | 65 | 0.14 |
| 10 | 300 | 389 | 125 | 89 | 150 | 75 | 0.29 |
| 12 | 300 | 383 | 125 | 83 | 150 | 75 | 0.40 |
| 14 | 330 | 420 | 140 | 90 | 165 | 85 | 0.66 |
| 16 | 400 | 516 | 170 | 116 | 200 | 100 | 0.89 |
| 20 | 440 | 572 | 200 | 132 | 220 | 120 | 1.60 |
| 22 | 440 | 585 | 220 | 145 | 220 | 130 | 2.27 |
| 24 | 520 | 697 | 255 | 177 | 260 | 150 | 2.82 |
| 30 | 520 | 695 | 255 | 165 | 260 | 160 | 4.23 |
| 36 | 600 | 780 | 295 | 185 | 300 | 180 | 7.10 |
Static cable tensioning, stays and securing arrangements.
To request DIN 1480 Stub End Turnbuckle, please specify thread diameter and pitch, body length, end fittings, adjustment range and finish. Include the quantity, delivery destination and any packaging or documentation requirements so our team can confirm the available configuration.
Throughout more than 23 years, has built an enviable reputation as a leading supplier of rigging hardware products, chains and steel wire rope accessories.
Used these DIN 1480 stub end turnbuckles on a warehouse cable bracing job. The solid stub ends weld clean — no porosity, no cracking after cooling. Forged carbon steel feels dense and heavy, not cheap cast. Threads are precise, body rotates smoothly for fine tension adjustment. Pulled to spec on 10mm guy wires, everything is rock solid. Will reorder for the next phase.
