| NOMINAL SINE （IN） | WORKING LOAD LIMIT（T） | WEIGHT EACH （KG） | DIMENSIONS（MM） | TOLERANCE +/- | |||||||||
| A | B | D | F | G | K | M | P | R | G | A | |||
| 1/4 | 1/2 | 0.06 | 11.90 | 7.85 | 6.35 | 15.50 | 19.10 | 40.40 | 24.60 | 39.60 | 6.35 | 1.50 | 1.50 |
| 5/16 | 3/4 | 0.10 | 13.50 | 9.65 | 7.85 | 19.10 | 25.40 | 48.50 | 29.50 | 46.20 | 7.85 | 1.50 | 1.50 |
| 3/8 | 1 | 0.15 | 16.80 | 11.20 | 9.65 | 23.10 | 31.00 | 58.50 | 35.80 | 55.00 | 9.65 | 3.30 | 1.50 |
| 7/16 | 1-1/2 | 0.22 | 19.10 | 12.70 | 11.20 | 26.90 | 36.10 | 67.50 | 41.10 | 63.50 | 11.20 | 3.30 | 1.50 |
| 1/2 | 2 | 0.34 | 20.60 | 16.00 | 12.70 | 30.20 | 41.40 | 77.00 | 46.00 | 71.00 | 12.70 | 3.30 | 1.50 |
| 5/8 | 3-1/4 | 0.67 | 26.90 | 19.10 | 16.00 | 38.10 | 51.00 | 95.50 | 58.50 | 89.50 | 16.00 | 3.30 | 1.50 |
| 3/4 | 4-3/4 | 1.14 | 31.80 | 22.40 | 19.10 | 46.00 | 60.50 | 115.00 | 70.00 | 103.00 | 20.60 | 6.35 | 1.50 |
| 7/8 | 6-1/2 | 1.74 | 36.60 | 25.40 | 22.40 | 53.00 | 71.50 | 135.00 | 81.00 | 120.00 | 24.60 | 6.35 | 1.50 |
| 1 | 8-1/2 | 2.52 | 42.90 | 28.70 | 25.40 | 60.50 | 81.00 | 151.00 | 93.50 | 135.00 | 25.40 | 6.35 | 1.50 |
| 1-1/8 | 9-1/2 | 3.45 | 46.00 | 31.80 | 28.70 | 68.50 | 91.00 | 172.00 | 103.00 | 150.00 | 31.80 | 6.35 | 1.50 |
| 1-1/4 | 12 | 4.90 | 51.50 | 35.10 | 31.80 | 76.00 | 100.00 | 191.00 | 115.00 | 165.00 | 35.10 | 6.35 | 3.30 |
| 1-3/8 | 13-1/2 | 6.24 | 57.00 | 38.10 | 35.10 | 84.00 | 111.00 | 210.00 | 127.00 | 183.00 | 38.10 | 6.35 | 3.30 |
| 1-1/2 | 17 | 8.39 | 60.50 | 41.40 | 38.10 | 92.00 | 122.00 | 230.00 | 137.00 | 196.00 | 41.10 | 6.35 | 3.30 |
| 1-3/4 | 25 | 14.20 | 73.00 | 51.00 | 44.50 | 106.00 | 146.00 | 279.00 | 162.00 | 230.00 | 54.00 | 6.35 | 3.30 |
| 2 | 35 | 21.20 | 82.50 | 57.00 | 51.00 | 122.00 | 172.00 | 312.00 | 184.00 | 264.00 | 51.00 | 6.35 | 3.30 |
| 2-1/2 | 55 | 38.60 | 105.00 | 70.00 | 66.50 | 145.00 | 203.00 | 377.00 | 238.00 | 344.00 | 66.50 | 6.35 | 6.35 |
| 3 | 85 | 56 | 127.00 | 82.50 | 76.00 | 165.00 | 216.00 | 429.00 | 279.00 | 419.00 | 89.00 | 6.35 | 6.35 |
Throughout more than 23 years, has built an enviable reputation as a leading supplier of rigging hardware products, chains and steel wire rope accessories.
High quality 209-210 type anchor shackle, drop forged carbon steel material, heat treated for high tensile strength. Finished with hot dip galvanized to achieve excellent anti-rust and anti-corrosion effect, suitable for saltwater and outdoor harsh environment. Standard size, stable working load limit and reliable safety factor. Widely used for marine rigging, ship mooring, port hoisting, cargo fixing and various heavy duty lifting connection works. Solid structure, easy installation, durable and safe for long-term industrial use.
High quality DIN 82101 D-type shackle, drop forged carbon steel material, heat treated for high tensile strength. Available in hot dip galvanized and plain finish, good anti-rust performance. Standard European type Dee shackle with stable working load limit, safe 6:1 safety factor. Widely used for lifting, rigging, towing, marine, construction and cargo binding. Strict quality inspection, durable and reliable for heavy duty industrial use.
Heavy-duty European Dee Shackle, forged from high-quality carbon steel for superior tensile strength and load capacity. The robust D-shape and precision screw pin ensure stable locking and safe use under heavy loads. Galvanized treatment provides effective protection against rust and wear, ideal for industrial lifting, construction rigging and heavy equipment connection.
