• Ratchet Type Load Binder.
• Drop Forged
• Powder Coating
• Satisfies US requirements.
• Grade 43 or Grade 70.
| Min-Max | WLL | Proof | Breaking | Weight | Handle | Dimensions(in) | |||||
| Chain | Load | Load | Length | ||||||||
| Size (in) | (lbs) | (lbs) | (lbs) | (lbs ) | (in) | A | B | C | E | E1 | F |
| 5/16-3/8 | 5400 | 10800 | 19000 | 12.11 | 14.00 | 14.00 | 1.38 | 2.75 | 13.70 | 21.70 | 0.79 |
| 3/8-1/2 | 9200 | 18400 | 33000 | 14.70 | 14.00 | 14.00 | 1.38 | 2.75 | 13.70 | 21.70 | 1.02 |
| 1/2-5/8 | 13000 | 26000 | 46000 | 14.55 | 14.00 | 14.00 | 1.38 | 2.75 | 13.70 | 22.00 | 1.00 |
| Min-Max | WLL | Proof | Breaking | Weight | Handle | Dimensions(in) | ||||||
| Chain | Load | Load | Length | |||||||||
| Size (in) | (lbs) | (lbs) | (lbs) | (lbs ) | (in) | A | B | C | E | E1 | F | G |
| 1/4-5/16 | 2200 | 4400 | 7800 | 3.52 | 7.16 | 7.16 | 0.89 | 1.77 | 16.22 | 21.26 | 17.79 | 0.35 |
| 5/16-3/8 | 5400 | 10800 | 19000 | 12.11 | 14.00 | 14.00 | 1.38 | 2.75 | 22.94 | 30.94 | 25.13 | 0.50 |
| 3/8-1/2 | 9200 | 18400 | 33000 | 14.70 | 14.00 | 14.00 | 1.38 | 2.75 | 22.94 | 33.25 | 27.63 | 0.63 |
| 1/2-5/8 | 13000 | 26000 | 46000 | 14.55 | 14.00 | 14.00 | 1.38 | 2.75 | 22.94 | 24.38 | 29.44 | 0.72 |
Throughout more than 23 years, has built an enviable reputation as a leading supplier of rigging hardware products, chains and steel wire rope accessories.
Heavy duty ratchet load binder, drop forged steel construction with high tensile strength. Labor-saving ratchet tightening design, easy to operate and fast tensioning. Electro-galvanized surface for rust & corrosion resistance. Widely used for truck cargo binding, transportation fixing and chain tensioning. Factory direct supply, complete sizes and OEM available.
