The G80 High Tensile Hook uses an illustrated connection for compatible rigging components. Compare the throat opening, attachment dimensions and load data below.
The G80 High Tensile Hook uses an illustrated connection for compatible rigging components. Compare the throat opening, attachment dimensions and load data below.
![]()
![]()
| Size(mm) | Weight | wll | B.L | Dimensions(mm) | |||
| Per pc | |||||||
| (kgs) | (Ton ) | (Ton ) | L±0.3 | A±0.3 | B±0.3 | R±0.3 | |
| 9 | 0.5 | 2.5 | 10 | 143 | 13.5 | 90.5 | 18.5 |
| 11 | 0.85 | 3.75 | 15 | 177 | 15.5 | 109.5 | 22 |
| 13 | 1.38 | 5.4 | 21.6 | 205 | 17.7 | 129 | 25.5 |
Hook connections matched to the selected model, chain grade and rated capacity.
To request G80 High Tensile Hook, please specify model, chain size and grade, attachment dimensions, throat opening and required rated load. Include the quantity, delivery destination and any packaging or documentation requirements so our team can confirm the available configuration.
