The G80 Eye Type Self-Locking Hook uses an eye connection for compatible rigging components. The self-locking configuration is shown in the drawing; match the hook to the required assembly.
The G80 Eye Type Self-Locking Hook uses an eye connection for compatible rigging components. The self-locking configuration is shown in the drawing; match the hook to the required assembly.
![]()
| size | Weight | WLL | B.L | Dimensions(mm) | |||||
| Per Pc | |||||||||
| (mm) | (kgs.) | (TON) | (TON) | A | B | E | E1 | L1 | L |
| 6 | 0.71 | 1.12 | 4.48 | 32.5 | 24 | 35 | 28 | 152 | 184 |
| 7/8" | 1.15 | 2 | 8 | 36 | 29.5 | 40 | 35.8 | 189 | 228 |
| 10 | 1.86 | 3.15 | 12.6 | 42 | 35 | 50 | 48 | 224 | 270 |
| 13 | 3.51 | 5.3 | 21.2 | 50 | 41 | 60 | 52.5 | 267 | 324 |
| 16 | 7.33 | 8 | 32 | 61 | 56.8 | 65 | 63.3 | 355.6 | 406 |
| 18/20 | 10.3 | 12.5 | 50 | 72 | 63 | 80 | 86 | 378.2 | 460.5 |
| 22 | 17.5 | 15 | 60 | 97 | 98 | 83 | 76 | 466 | 564 |
| 26 | 23 | 21.2 | 84.8 | 123 | 115 | 106 | 96 | 544 | 661 |
| 32 | 81 | 31.5 | 126 | 140 | 146 | 140 | 135 | 679 | 892 |
Hook connections matched to the selected model, chain grade and rated capacity.
To request G80 Eye Type Self-Locking Hook, please specify model, chain size and grade, attachment dimensions, throat opening and required rated load. Include the quantity, delivery destination and any packaging or documentation requirements so our team can confirm the available configuration.
