G80 European Type Omega Link
G80 European Type Omega Link from china
G80 European Type Omega Link
G80 European Type Omega Link
G80 European Type Omega Link from china
[ G80 Chain Components ]

G80 European Type Omega Link

Product Attributes
  • Material: Alloy Steel

  • Standard: EN Standard

  • Certificates: ISO/CE

  • Size: All / Different Size Available

  • Sample: Free

  • Package: Carton/Gunny bag/Pallet / As customer’s requirements.

Share To

Product Details

    ● G80 European Type Omega Link

    ● Quenched and Tempered.

    ● Powder coated.

    ● Safety Factor: 4:1.

    ● Forged alloy steel.

    ● Suit for EN818-2 G80 chain.


TABLE PARAMETER

sizeWeightWLLB.LDimensions(mm)
Per Pc
(mm)(kgs.)(TON)(TON)ABDHL
60.121.124.4884120.52552
7/8"0.2228105223.53568.5
100.363.1512.6126231.540.581
130.715.321.215814154108
161.3832199949.564126
202.212.550231185875.6152

Drop forged Grade 80 alloy steel, quenched & tempered, complies with EN1677-1 standard.

100% magnetic particle inspection and proof load tested, safety factor 4:1 for overhead lifting.

Removable heavy-duty pin design, easy assembly and disassembly for chain sling installation & maintenance.

Wide throat opening, compatible with EN818-2 G80 lifting chains, eye hooks and rigging components.

Smooth curved bearing surface for uniform load distribution, reduces stress concentration.

Powder coated finish (yellow/red), excellent anti-corrosion performance for indoor & outdoor service.

Complete size range from 6mm to 20mm, widely used for European standard lifting rigging assembly.
