The G80 European Type Eye Shortening Grab Hook uses an eye connection for compatible rigging components. The grab profile is selected to match the specified chain size for length adjustment.
The G80 European Type Eye Shortening Grab Hook uses an eye connection for compatible rigging components. The grab profile is selected to match the specified chain size for length adjustment.
![]()
| size | Weight | WLL | B.L | Dimensions(mm) | ||||
| Per Pc | ||||||||
| (mm) | (kgs.) | (TON) | (TON) | L | E | D | H | R |
| 6 | 0.14 | 1.12 | 4.48 | 75.3 | 8 | 13.5 | 17.9 | 51.4 |
| 7/8" | 0.245 | 2 | 8 | 91.2 | 10.8 | 18 | 20 | 61.5 |
| 10 | 0.65 | 3.15 | 12.6 | 122 | 13 | 20 | 29 | 80 |
| 13 | 1.39 | 5.3 | 21.2 | 158 | 16.5 | 26 | 42.8 | 99.7 |
| 16 | 2.2 | 8 | 32 | 169 | 20 | 30.5 | 47.7 | 104 |
| 20 | 4.6 | 12.5 | 50 | 219 | 25 | 37.5 | 56 | 140 |
| 22 | 8.2 | 15 | 60 | 259 | 28 | 44 | 68 | 165 |
| 26 | 9.8 | 21.2 | 84.8 | 298 | 30 | 44 | 77 | 188.8 |
| 32 | 19.4 | 31.5 | 126 | 361 | 38 | 57 | 95 | 228 |
Hook connections matched to the selected model, chain grade and rated capacity.
To request G80 European Type Eye Shortening Grab Hook, please specify model, chain size and grade, attachment dimensions, throat opening and required rated load. Include the quantity, delivery destination and any packaging or documentation requirements so our team can confirm the available configuration.
Throughout more than 23 years, has built an enviable reputation as a leading supplier of rigging hardware products, chains and steel wire rope accessories.
These G80 European‑type eye shortening grab hooks are precision heat‑forged. It grips chain links firmly without slipping under load. G80 high‑strength grade is ideal for adjusting sling length. Galvanized finish offers reliable rust resistance. Perfect for rigging assembly, will re‑order.
